Name: Aluminum Door And Window Small Profile Extrusion Press Extrusion Machine
Brand: Aluminum Door And Window Small Profile Extrusion Press Extrusion Machine
SKU: HX-630T-029
Price: 1 USD
Availability: InStock
Rating: 5 (160 reviews)

Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat

Eigenschaften

Technische Daten

Model Number: HX-630T-029

After-sales Service Provided: Engineers available to service machinery overseas

Product name: aluminium extrusion press small aluminum extrusion machine

Application: Door and window profile,construction and industrial profile

Main cylinder: forged steel

Aluminum bar: for 4 inch by 630T press

Heating mode: natural gas,electricity,coal.etc

Weight of 630T press: 25 Tons

Installation period: around 1 month

Engineers: between 2 and 4 people

Water,electricity,gas are ready: go for installation

Skilled workers: between 2 and 3 people by the buyer

Grundinformation

Model Number: HX-630T-029

Zahlung und Versand AGB

Packaging Details: 1.Nude 2.Water-proof cloth 3.Wooden case 4.Reinforce packaging aluminium extrusion press small aluminum extrusion machine

Supply Ability: 80 Set/Sets per Year aluminium extrusion press small aluminum extrusion machine

Produkt-Beschreibung

small aluminum extrusion machine

Turnkey Project

Specification

NO.	Item	Type	QTY
1	Hydraulic system working pressure	21Mpa
2	Extrusion Pressure	Main Cylinder 633T
2	Extrusion Pressure	Lateral Cylinder 51.5T
3	Lateral cylinder return force	16T
4	Locking force of container	51T
5	Shear pressure	32T
6	Extrusion working speed(maximum)	8.8mm/s
7	Master plunger fast forwarding speed	315mm/s
8	Master plunger fast backward speed	348mm/s
9	Closing speed of container	136mm/s
10	Open speed of container	83mm/s
11	Shear down speed	216mm/s
12	Shear up speed	442mm/s
13	The inner hole range of extrusion tube	ID Φ85-115
13	The inner hole range of extrusion tube	L 500mm
14	The dimension range of aluminum bar	IDΦ80-Φ110
14	The dimension range of aluminum bar	L 450mm
15	The total power of motor	55KW
16	Heating power for extrusion tube	T 1.2KW*15=18KW
17	Operation Mode	Manual or automatic single stoke
18	External dimension(LWH)	7m2.8m3.2m

Product Description

Finished Products

Application
